NX CAD for Manufacturing

Enrollment is Open

Choose Your Class Qty Cost Per Student
April 30- May 2, 2024 | NX CAD for Manufacturing
8 Left:
$1,980.00
June 25-27, 2024 | NX CAD for Manufacturing
8 Left:
$1,980.00
August 20-22, 2024 | NX CAD for Manufacturing
8 Left:
$1,980.00
October 15-17, 2024 | NX CAD for Manufacturing
8 Left:
$1,980.00
Reserving Total

NX CAD for Manufacturing (TR20800)

3 Day Class

This course is intended for NX CAM users who often require the creation of additional geometry to machine a part feature. The primary areas of CAD are covered, including CAD environment, sketching, basic modeling, base curves, fixture assemblies, simple patterns, and drafting for documentation.



Prerequisites:

Students attending this course are expected to be competent in NC/CNC programming principles and have completed one of the following Swoosh courses; NX CAD Fundamentals (TR10200) or NX for Experienced CAD Users (TR10300).

DAY 1



Sketching

  • Sketching Overview
  • Create Sketch Commands
  • Creating Sketch Curves
  • Editing and Modifying Sketch Curves
  • Sketch Features in Part Navigator

DAY 2



Feature Modeling

  • Coordinate Systems
  • Construction Functions
  • Creating an Extruded Feature
  • Selection Intent
  • Creating a Revolved Feature
  • Editing Extrude and Revolve Features
  • Boolean Features
  • Detail Features

DAY 3



Datum Features

  • Create and Edit: Datum Planes, Datum Axes and Datum CSYS
  • Associative Points
  • Visibility and Selection Management



Assemblies

  • Creating an assembly
  • The Assembly Navigator, Work and Displayed Part
  • Opening an assembly
  • Part versions
  • Assembly Load Options
  • Positioning Components
