NX Milling Manufacturing Fundamentals-NX2206 @CCAT

Date and Time:

January 1, 2021 8:30 am - December 31, 2023 - 5:00 pm

Enrollment is Open

Choose Your Class	Qty	Cost Per Student
October 10-13, 2023 \| NX Mill Manufacturing Fundamentals	4 Left:	$2,200.00 2200

Reserving Total

About The Events

About the NX Manufacturing Fundamentals training class.

Name: NX Milling Manufacturing Fundamentals-NX2206 @CCAT
Start: 2021-01-01 02:30:00 CST
End: 2023-12-31 17:00:00
Location: CCAT’s Advanced Technology Center

Looking for a beginner NX CAM training class? This 4-day NX Mill Manufacturing Fundamentals class is perfect for those new to Siemens NX CAM and trying to become CAM certified.

NC programmers new to NX CAM will understand how to create CAM certified tool paths for 2 and 3 axis milling/drilling centers within the software. Also covered includes cutting / non-cutting motions and other NX operations. Upon completion, user will have the capability to create and modify output verified 3-axis NC programs for milling machines.

The manufacturing user interface, coordinate systems, tools, and milling operations are discussed during the 4-day beginner NX Manufacturing Fundamentals training course.

Prerequisites:
• Must have NC/CNC programming methods and machinery knowledge
• Thorough understanding of NC/CNC programming principles

* Please Note: Until further notice, all classroom training classes will take place in a virtual environment. This is to ensure the safety of our students and instructors during these uncertain times. Thank you for your understanding

Course No: TR20300

Software: NX 2206
Class Duration: 4 Days
Class Location: Virtual Classroom*
Cost Per Student: $2,200

John Vincent
NX CAM Instructor
Swoosh Technologies

^{“I’m not a fan of death-by-powerpoint, so don’t expect to see that in my classes!}^{“ Get to know John Vincent.}

What does my training schedule look like?

Here’s a quick glimpse on what to expect during class.

DAY 1
NXCAM 101

Day 1 of training covers NX CAM’s user interface and the machining environment. Topics include:

Creating Programs | Tips to Ease Use
Navigator Views | Coordinate Systems

DAY 3
NXCAM 103

Over 21+ topics on Visualization, Planar Milling, and Hole Making are lined up for class. Topics include:

3D Dynamics | Machine Control
Machine Cycle | Cutting Parameters

DAY 2
NXCAM 102 (18 topics)

On Day 2, Master Model concepts, cavity milling and face milling principles are covered. Other topics include:

Assemblies | Tool Creation
Tool Path Creation | Mill Geometry

DAY 4
NXCAM 104

Final day of class! We’ll send you back to the real world with basic to intermediate techniques, including;

Adaptive Milling | Fixed Axis Contouring
Z Level Milling | Post Processing
Shop Documentation

Until further notice, all training sessions will be taking place in a virtual environment
